Strata Airforce M20 – Industrial Welding Fume Extractor!
The Strata Airforce M20 industrial welding fume extractor is the ideal solution for extracting fumes directly from the welding torch. This fume extractor is equipped with two powerful by-pass motors that guarantee up to 190m3/h of airflow each. It integrates seamlessly with the welding machine, offering direct control. A sophisticated sensor on the vacuum detects current flow in the ground cable through a special clip.
Includes:
- a cellulose filter for safe welding fume filtration, with optional H14 filter – available on request
- a lightweight ‘Ready to Use’ 4.5m Strata MIG welding torch with integrated fume extraction at the nozzle
- a 5m fume hose
Specifications
| Motor type | 2 by-pass motors |
|---|---|
| Power (KW) | 2.4 |
| Voltage | Frequency (V | Hz) | 230 | 50 |
| Max vacuum (mbar) | 250 |
| Max Suction (m3/hr) | 300 |
| Max Air Flow (CFM) | 224 |
| Noise level (dBA) | 72 |
| Capacity (L) | 20 |
| Dimensions (mm) length*width*height | 534 x 471 x 983 |
| Weight | 38kg |
| Primary Filter | Class M Cartridge |
| Secondary Filter | Spark trap |
| Optional Filter | H14 Cartridge |
